ACF Bonding Machine Working Videos:

Anisotropic Conductive Film (ACF) bonding machines are essential in the electronics industry, particularly for bonding flexible circuits or COF (Chip-On-Film) chips onto target substrates. These machines apply heat, pressure, and time to ensure a strong and reliable bond. Working videos of ACF bonding machines can provide valuable insights into their operation and applications. Here is a classification and introduction to different types of ACF bonding machine working videos:

1. Semi-Automatic ACF Bonding Machines

Semi-automatic ACF bonding machines require manual assistance for some steps of the bonding process. These machines typically include a pre-bonding station and a final bonding station. The pre-bonding station is used to position the ACF tape on the substrate, while the final bonding station applies heat and pressure to complete the bond. For example, the Semi-Automatic COF/COG/COP Pre-bonding Machine OL-COF003 can automatically peel and cut 1 or 2 layers of ACF tape and attach it to the substrate. The heating method is constant heating, and the machine can handle substrates with a maximum length of 120mm and a width of 120mm, with an accuracy of ±0.1mm and a temperature range from room temperature to 300°C . Our Semi-automatic ACF bonding machines: EC Cleaning machine OL-Q006, OL-Q017，ACF tape attaching machine OL-A003,OL-A0156, COG/COP/COF pre bonding machine OL-COF003,OL-COF156, COG/COP/COF main bonding machine OL-C012,OL-CBD156, FOG/FOF/FOP bonding machine OL-F003,OL-FOG156， FOG/FOB/FOP/FOF/T-FOG bonding machine OL-F006,OL-FOB156, and other models:OL-FC005,OL-CBS003,OL-FS003,OL-F156,OL-F0712,

2. Fully Automatic ACF Bonding Machines

Fully automatic ACF bonding machines are designed to handle the entire bonding process without manual intervention. These machines are highly efficient and can handle high-volume production. They typically include features such as automatic tape cutting, alignment, and bonding. For example, the Fully Automatic COG/COF/COP Bonding Machine is part of a fully automatic ACF bonding line that includes substrates loading, terminal cleaning, and COF punching machines. These machines ensure high precision and repeatability, making them ideal for large-scale production . we have OL-600,OL-800,OL-1000,OL-1500,0L-2000,different series.

3. ACF Laminating Machines

ACF laminating machines are used to apply ACF tape to the substrate before the final bonding process. These machines ensure that the ACF tape is accurately positioned and pre-bonded to the substrate. For example, the ACF Pre-bond Machine OL-A003 is a semi-automatic pre-bonding machine that pre-bonds IC or COF on the panel that has been attached to the ACF. The pick and place of the panel is achieved manually, and the pre-alignment is automatically completed by the equipment .

4. Constant Heat and Pulse Heat Systems

ACF bonding machines can use either constant heat or pulse heat systems. Constant heat systems maintain a consistent temperature throughout the bonding process, while pulse heat systems apply heat in short bursts. For example, the Constant Heat ACF Bonder (Table-Top) – OL-F003 is designed for thermocompression bonding and can handle product sizes up to 200mm x 150mm. It features a manual stage and up to 2 sets of vision cameras for precise alignment .

5. Top-Bottom Alignment Machines

Top-bottom alignment machines are used to bond FPC (Flexible Printed Circuit) or Zebra paper onto PCB (Printed Circuit Board) or glass with ACF attached. These machines ensure precise alignment of the components before applying heat and pressure to complete the bond. For example, the Top-Bottom Alignment FOG/FOB Bonding Machine (Constant Heat) OL-F006 is a manual bonding machine that bonds FPC/Zebra paper on the PCB/Glass with ACF attached. The pick and place and alignment of the PCB/Panel are done manually, and the ACF bonding is done automatically. This machine is suitable for 1″ to 12″ flat glass and flexible screen products .

Conclusion

ACF bonding machines are crucial in the electronics industry for creating reliable and precise electrical connections. Working videos of these machines can help users understand the operation and features of different types of ACF bonding machines. Whether you are looking for semi-automatic or fully automatic solutions, understanding the capabilities and applications of ACF bonding machines can help you make informed decisions for your production needs. By choosing the right ACF bonding machine, you can ensure high-quality and efficient production processes.
