Single sided multi stage cleaning machine -OL-QX012

This device is a manual multilateral LCD terminal cleaning machine that cannot be cleaned with cloth or plasma on ITO terminals that require the attachment of conductive film (ACF) PaneL.

LCD SIZE： 5~12inch
Capacity: 200~450 pieces／hour;
Cleanliness: Below 30 degrees (originally below 65 degrees);
Chuck specifications: 20*5mm,Can be changed according to customer requirements;
Position repetition accuracy: 0.2mm；
Working air pressure: 0.4~0.6Mpa;
Power Supply: 220V，50HZ，2100W;
Total weight: 281Kg;
Dimensions: L900*W800*H1020;
