Dual station pulse pre bonding servo Main Bonding all-in-one machine OL-FC005

This equipment is a dual station Pre and Main Bonding all-in-one machine, with left station Pre Bonding and right station Main Bonding.
The left workstation is a manual pulse Pre Bonding machine for down alignment, which is a device used to connect FPC, COF, or zebra paper on a panel that has already been attached with a conductive film (ACF) for alignment and Pre Bonding. The removal and alignment of the panel are manually completed, while Bonding is automatically completed by the device.
The right workstation is a manual Main Bonding machine, which is a device that performs Main Bonding on glass or flexible displays that have already been pre Bonded with IC, FPC, COF, or zebra paper. The product is manually picked and placed, and the device automatically bonding.

The left workstation of this device meets the alignment and Pre Bonding requirements for high accuracy COF to TFT-LCD, OLED-LCD, ON-CELL, IN-CELL, and flexible OLED. The right workstation is mainly used for Main Bonding alignment between COF and FPC, mainly for COF repair and small batch production.

1. Adopting a high accuracy imaging unit, the amplification bit is increased to nearly 300 times;
2. Add manual room temperature Pre Bonding function to solve COF bending problem;
3. The use of both upper and down light sources for alignment enhances the clarity of the alignment process.
4. Adopting Pulse heating method, suitable for various products.
5. The PLC control action increases the accuracy temperature control module to control the temperature, improving the stability of the entire machine.

LCD SIZE： 3~7inch;
Capacity: About130 pieces／hour;
COF range: 11~65mm;
Pre bonding accuracy: X±0.006mm,Y±0.006mm;
Main bonding accuracy: X±0.008mm,Y±0.008mm;
Pre-Bonding Heating method: Pulse heating
Pre-Bonding Temperature range: RT-400℃;
Main-Bonding Heating method: Constant temperature heating
Main-Bonding Temperature range: RT-400℃;
Working air pressure: 0.4~0.6Mpa;
Power Supply: 220V，50HZ，2500W;
Total weight: 280Kg;
Dimensions: L700*W750*H1450;
